NEW!!!! - Nexus Plug-in ECU - Honda DC5 (05-06)

The Nexus Honda DC5 (04-06) plug-in brings advanced control and wireless connectivity to your Honda DC5

Supported Models

Honda Integra DC5 - (04-06) Manual Transmission

Effortless Setup

Get up and running quickly using the intuitive Nexus Set-up Wizard.

Wireless Control

Connects directly via Bluetooth to the Haltech Connect App for easy adjustments and monitoring.

Future Proof

Expand your functionality easily with the optional expansion harness and CAN devices.

Simple Install

Supplied with a mounting bracket for easy fitment in the factory ECU location.

This Nexus Plug-in ECU is compatible with the following vehicles:

• Honda Integra / Acura RSX DC5 (05-06), manual transmission only

Nexus Plug-in ECU includes

• Nexus Honda DC5 Plug-in ECU
• Air temperature + wideband expansion harness 2.5m (8') (HT-189000)
• Air temp sensor (1/8” NPT) (HT-010206)
• Aluminum weld on fitting 1/8 NPT-27 TPI for air temp sensor
• Mounting brackets and hardware
• 2.5m vacuum hose and T-piece
• Haltech USB-C cable
• Quick start guide

Supported transmissions

• Factory manual transmission (5- or 6-speed)
• Does not support automatic transmissions

OEM functionalities supported (notable ones)

• VTEC solenoid
• VTC solenoid
• IMRC (Dual Intake Runner System)

Supports serial communications with the Multiplex Control Unit

• Coolant temperature display (dash)
• Battery warning light (dash)
• A/C request signal (climate control)

Supports serial communications with the Immobiliser

OEM functionalities not supported (notable ones)

• Automatic transmission
• OEM 4-wire wideband sensor

Additional functionalities

• Drive by wire throttle and pedal systems
• Flex fuel
• Boost control

Connections

Outputs

• 4 x Ignition
• 4 x Injection (peak and hold)
• 8 x Digital Pulsed Outputs (DPO)
• 9 x Low current DPOs (fixed functions)
• 2 x Half Bridge Outputs (HBO) - eg DBW support
• 2 x Fixed function HBOs
• 1 x ECR output
• 1 x 5V sensor supply

Inputs

• 1 x Onboard MAP sensor (4 Bar)
• 15 x Analog Voltage Inputs (AVI)
• 2 x Engine Position Inputs (Trigger and Home)
• 6 x Synchronised Pulsed Inputs (SPI)
• 1 x Knock Inputs
• 1 x Onboard Wideband Controller (NTK/LSU 4.9)
• 1x Ignition Switch Input

Other

• 128MB Onboard logging
• 4 channel onboard Oscilloscope

Communications

• 1 x CAN Bus Network
• Hi-Speed USB 2.0 C-type Connection
• WiFi communications through internal antenna

Serial communications

• Multiplex Control Unit
• Immobiliser light

Optional Accessories (sold separately)

• HT-189002 - IO Expansion Harness 2.5m (8’)
• HT-189003 - DBW Expansion Harness 2.5m (8’)
•HT-010746 - LSU4.9 Wideband Hardware Pack

Download the Quickstart guide HERE!
